Arcam AVA15 AV Receiver

Arcam AVA15 AV Receiver

The Arcam AVA15 AV Receiver is available for demonstration in our Hull store by request.

The Arcam AVA15 AV Receiver is designed for listeners who demand cinematic immersion without sacrificing musical accuracy. Engineered in Cambridge, UK, the AVA15 represents over three decades of Arcam surround sound expertise, combining audiophile-grade amplification with the latest immersive audio technologies.

High-Power Class D Amplification

Built around high-power ARCAM Class D amplification, the Arcam AVA15 delivers 9 x 100 watts into 8 ohms, providing exceptional control, low distortion, and effortless dynamics. Whether driving compact surround speakers or full-range floorstanders, the AVA15 maintains clarity and composure even during demanding movie soundtracks and high-resolution music playback.

Dolby Atmos & DTS:X Immersive Surround Sound

The Arcam AVA15 AV Receiver fully supports Dolby Atmos® and DTS:X®, allowing sound to move freely around and above the listener for a truly three-dimensional experience. With nine channels of onboard amplification, it easily powers 7.1.2 or 5.1.4 speaker layouts, making it ideal for modern immersive home cinema installations.

Precision Object-Based Audio

Precise object-based audio placement ensures dialogue remains clear, effects are accurately positioned, and soundtracks retain scale and realism. From subtle ambient cues to explosive action scenes, the Arcam AVA15 places you firmly at the centre of every performance.

Dirac Live Room Correction

To deliver consistent performance in real-world rooms, the Arcam AVA15 includes Dirac Live® Room Correction. This advanced calibration technology measures your room acoustics and corrects frequency response and timing issues, ensuring balanced, accurate sound at the listening position.

Advanced Room Optimisation Options

For even greater optimisation, the AVA15 can be upgraded with Dirac Live Bass Control and Dirac Live Active Room Treatment. These upgrades improve low-frequency integration and reduce the impact of problematic room reflections, particularly beneficial in dedicated home cinema environments.

High-Resolution Streaming & Connectivity

The Arcam AVA15 AV Receiver supports Apple AirPlay, Google Cast, Spotify Connect, TIDAL Connect, and Qobuz Connect, enabling direct streaming from leading lossless music services without compromising audio quality.

Smart Control & Premium Display

Wireless playback is enhanced with Bluetooth featuring Snapdragon Sound and Auracast, delivering improved resolution and stability. The ARCAM Radia App provides simple setup and intuitive control from iOS, Android, Windows devices, and PCs, while the Bluetooth remote allows reliable operation even when the unit is out of sight. A large 6.5-inch high-resolution colour display ensures clear visibility of system status and metadata from across the room.

Arcam AVA15 AV Receiver Specification:

• Amplification
  Amplifier channels: 9 (Class D)
  Continuous power output (0.5% THD):
  100W into 8Ω (20Hz–20kHz, 2 channels driven)
  150W into 4Ω (1kHz, 2 channels driven)
  75W into 8Ω (20Hz–20kHz, 9 channels driven)
  90W into 4Ω (1kHz)
  Harmonic distortion: 0.01% at 80% power (8Ω, 1kHz)
• Preamplifier Outputs
  Number of outputs: 12 (RCA, single-ended)
  Peak output level per channel: 2V RMS
  THD+N (20Hz–20kHz): –100dB
• Decoding / Encoding
  Maximum channel count: 12
  Reassignable channels: Front, Surround Back, Height
  Dolby Atmos, Dolby TrueHD, Dolby Atmos Height Virtualisation, Dolby Surround
  DTS:X, DTS-HD Master Audio, DTS Neural:X, DTS Virtual:X, MPEG-H
• Analogue Inputs
  Number of inputs: 3 (RCA pairs)
  Signal-to-noise ratio (A-weighted): 100dB
  Frequency response: 20Hz–20kHz ±0.2dB
• Digital Inputs
  Inputs: 2 Coaxial / 2 Optical (Toslink)
  Supported sample rates: up to 192kHz (Coax), up to 96kHz (Optical)
  Bit depths: 16 / 24-bit
  Signal-to-noise ratio (A-weighted): 100dB
  Frequency response: 20Hz–20kHz ±0.2dB
• Streaming & High-Resolution Audio
  ARCAM Radia Control, Spotify Connect, TIDAL Connect, Qobuz Connect, Roon Ready
  Apple AirPlay, Google Cast
  Supported formats: FLAC, WAV (LPCM), MQA, AAC, ALAC, AIFF, MP3, OGG, WMA
  Supported bit depth: 16 / 24-bit
  Supported sample rates: up to 192kHz
  Gapless playback
  Frequency response: 20Hz–20kHz ±0.05dB
• HDMI Connectivity
  Inputs / Outputs: 7 / 2
  HDMI / HDCP versions: 2.1a / 2.3
  Resolution support: up to 8K/60Hz or 4K/120Hz
  HDR formats: HDR, HDR10, HDR10+, HDR10+ Gaming, Dolby Vision, HLG
  HDMI features: VRR, ALLM, CEC, eARC/ARC (Zone 1), On-Screen Display
• Wireless Connectivity
  Bluetooth 5.4
  Profiles: A2DP Sink/Source, AVRCP, Snapdragon Sound, AAC, LE Audio, Auracast
  Wi-Fi: IEEE 802.11 a/b/g/n/ac (2.4GHz / 5GHz)
• General Specifications
  Power supply: 100–120V / 220–240V, 50–60Hz
  Max power consumption: 900W
  Idle power consumption: 59W
  Standby power consumption: 2W / 0.3W
  Dimensions (W x D x H): 432 x 407 x 170mm
  Weight: 10kg (net), 15.7kg (packed)
• Supplied Accessories
  Region-specific power cord(s)
  Rear panel cowl
  Bluetooth remote control with batteries
  Measurement microphone
  5m USB cable
  Quick start guide and safety documentation
