Luxman L-509Z Integrated Amplifier

Luxman L-509Z Integrated Amplifier

Luxman L-509Z Integrated Amplifier Review - What Hi-Fi Verdict

On offer we have our Ex -Display luxman amplifier available for £9500, a saving of £1500 For more information about this offer call us on 01482 223096 or email shop@fanthorpes.co.uk

Power and Performance

The Luxman L-509Z Integrated Amplifier stands as a testament to high-end audio engineering. With a power output of 120W per channel at 8Ω and 240W per channel at 4Ω, the Luxman L-509Z ensures dynamic and clear audio delivery. Its diverse input setup includes sensitivity and impedance specifications for Phono with Moving Magnet, Moving Coil-High gain, Moving Coil-Low gain, Line inputs, and Balanced input, enabling users to connect and optimize a wide array of audio sources.

Frequency Response and Audio Clarity

In terms of frequency response, the Luxman L-509Z is truly exemplary. For Phono input, it manages a frequency range from 20Hz to 20kHz with a precise deviation of ±0.5dB, fantastic for vinyl aficionados. The line input extends its range from 20Hz up to a remarkable 150kHz within a -3.0dB limit, perfect for high-definition audio playback. Moreover, the Luxman L-509Z boasts a minimal harmonic distortion, registering less than 0.006% at 8Ω, 1kHz, and below 0.06% at 8Ω across 20Hz to 20kHz.

Innovative Features and Build Quality

The Luxman L-509Z further distinguishes itself with the inclusion of the LECUA-EX volume control and the innovative LIFES 1.0 amplifier circuitry. This amplifier utilizes a Bipolar design with a 4-parallel push-pull output arrangement, all anchored by a robust EI-type 600VA power transformer. Such features culminate in the Luxman L-509Z's impressive damping factor of 330 (measured by the EIAJ method), indicating its superior ability to control speaker dynamics and optimize sound quality.

Physical Specifications and Accessories

From a physical standpoint, the Luxman L-509Z exudes durability and craftsmanship. Weighing in at 29.4kg (device alone) and 37.1kg with standard packaging, its dimensions are set at 440mm in width, 193mm in height, and 463mm in depth. This depth accounts for both the 20mm front knob and the 37mm rear terminal. Each Luxman L-509Z comes equipped with a RA-17A remote control and a specifically marked JPA-15000 power cable. Moreover, users should check the Y-lug terminal dimensions for speaker hookups to ensure a hassle-free setup.

Generous Part Exchange Offer

As you would expect from Fanthorpes Hi-Fi, we offer a generous part exchange against the Luxman L-509Z Integrated Amplifier. If you have any Hi-Fi equipment you wish to use as part payment, call us on 01482 223096 or email us at shop@fanthorpes.co.uk , and we will give you a price to change. This is a fantastic and hassle-free way of making the Luxman L-509Z more affordable.

Flexible Finance Options

Fanthorpes Hi-Fi can also offer buy-now-pay-later options on the Luxman L-509Z Integrated Amplifier, allowing you to spread or defer your payments over a year. If you are interested in taking advantage of our payment terms, email shop@fanthorpes.co.uk or call us on 01482 223096, and we will email an application form to you.

Luxman L-509Z Specification:

• Output Power: 120W per channel at 8Ω, 240W per channel at 4Ω
• Input Sensitivity / Impedance:
  • Phono (MM): 2.5mV / 47kΩ
  • Phono (MC-H): 0.3mV / 100Ω
  • Phono (MC-L): 0.1mV / 40Ω
  • Line: 180mV / 47kΩ
  • BAL Line: 180mV / 55kΩ
  • Main-In: 1.1V / 47kΩ
• Output Voltage: Pre Out: 1V
• Frequency Response: Phono: 20Hz - 20kHz (±0.5dB), Line: 20Hz - 150kHz (-3.0dB)
• Total Harmonic Distortion: 0.006% or less (8Ω, 1kHz), 0.06% or less (8Ω, 20Hz - 20kHz)
• S/N Ratio (IHF-A): Phono (MM): 87dB or more, Phono (MC-H): 70dB or more, Phono (MC-L): 62dB or more, Line: 106dB or more
• Volume Control: LECUA-EX
• Amplifier Circuit: LIFES 1.0
• Output Configuration: Bipolar / 4-parallel push-pull
• Power Transformer: EI type 600VA
• Damping Factor: 330 (EIAJ current injection method)
• Tone Control: Bass: ±8dB at 100Hz, Middle: ±8dB at 760Hz, Treble: ±8dB at 10kHz
• Power Supply Voltage: AC100V (50/60Hz)
• Power Consumption: 370W (Electrical Appliance and Material Safety Law), 130W (no signal), 0.4W (standby)
• Dimensions: 440mm (W) x 193mm (H) x 463mm (D), Depth includes front knob (20mm) and rear terminal (37mm)
• Weight: 29.4kg (body), 37.1kg (standard packaging)
• Accessories: Remote control (RA-17A), power cable (JPA-15000: with polarity mark)
• Speaker Terminal Y-Lug Dimensions: Width of part a: 16mm or less, Width of part b: 7mm or more (attachment may vary based on Y-lug shape)
