Project Phono Box RS Phono Stage

Project Phono Box RS Phono Stage

The Project Phono Box RS Phono Stage is available for demonstration in our Hull store by request.

The Phono Box RS is an ultra-low noise and distortion-free phono pre-amplifier for Moving Magnet (MM) and Moving Coil (MC) cartridges, made with the sophisticated audiophile in mind. The result is a device that not only offers a breath-taking performance, but is also extensively adjustable to work with any type of pick-up cartridge.

Internally, the Phono Box RS uses only the finest available components throughout in dual-mono configuration - like the SSM2019 pre-amplifier module from Analog Devices on the input stages, and Linear Technology's LT1010 as a high current buffer stage - which allows for a very clean sound, free of unwanted noise. The Phono Box RS is then connected into a system via either RCA or XLR connectors, making it one of the most affordable high-end balanced phono stages on the market. Due to the very low output impedance of the phono stage, it is easy to pair with a wide variety of quality cables.

For cartridge matching, there is an extensive list of settings adjustment available. On top of the usual Gain and Capacitance adjustments, the Phono Box RS boasts a fully adjustable dial for attenuating the Input Impedance. This allows for perfect matching with any Moving Coil cartridge on the market, and it can even be adjusted during playback to tailor the sound perfectly to your preference. To further suit individual tastes, there is also an option to choose between fully-passive RIAA or DECCA equalisation curves.

With the Phono Box RS, vinyl playback will never have sounded as clear, detailed and smooth than with this superlative phono stage.

Part Exchange Available

As you would expect from Fanthorpes hifi, we offer a generous part exchange against the Project Phono Box RS Phono Stage. If you have any hifi that you wish to use as part payment then either call us on 01482 223096 or email us at shop@fanthorpes.co.uk and we will give you a price to change. This is a fantastic and hassle-free way of making the Project Phono Box RS more affordable.

Finance Available

Fanthorpes hifi can also offer buy now pay later on the Project Phono Box RS Phono Stage, allowing you to spread or defer your payments over a year. If you are interested in taking advantage of our payment terms, email shop@fanthorpes.co.uk or call us on 01482 223096 and we will email an application form to you.

Project Phono Box RS Phono Stage Specification:

• Input Impedance Settings:
• Fixed: 10Ω or 47kΩ
• Variable: 10 - 1,200Ω
• Capacitance Settings: 100pF, 200pF, 300pF, 420pF, 520pF
• Output Impedance: 50Ω
• Gain Settings:
• RCA: 40dB, 43dB, 60dB
• XLR: 46dB, 56dB, 66dB
• Signal-to-Noise Ratio: -80dB (91dB - A Weighted)
• THD: 0.019%
• RIAA Accuracy: Within 0.3dB (20Hz - 20kHz)
• Subsonic: 20Hz / 12dB Per Octave
• Inputs: RCA & XLR
• Outputs: RCA & XLR
• Power Consumption: 150mA DC / <1W (Standby)
• Dimensions: 206 x 72 x 200mm, 206 x 72 x 210mm (Incl. Sockets)
• Weight: 2kg
