Technics SL1300G Turntable

Technics SL1300G Turntable

The Technics SL1300G Turntable is available for demonstration in our Hull store by request.

The new Technics SL-1300G turntable minimises vibrations, thanks to their advanced ΔΣ-Drive motor technology which enhances rotational accuracy. Giving you a superior sound quality and listening experience.

New Generation Grand Class Turntable

The Technic SL-1300G turntable is designed with a Hi-Fi focus, featuring Technics' advanced ΔΣ-Drive motor technology. This new system enhances rotational accuracy and minimises vibrations, resulting in superior sound quality. Key elements contributing to this performance include the coreless direct-drive motor and a three-layered platter, combined with a high-rigidity chassis.

Motor and Construction

The turntable's coreless direct-drive motor is notable for eliminating cogging, which can cause uneven rotation. The motor's twin-rotor design reduces bearing load and maintains high torque while minimising minute vibrations. The motor has been specially redesigned to avoid subtle vibrations that might impact sound quality. For increased rigidity, the motor's coil mounting base uses the same reinforcement pattern as the high-end SL-1000R/SP-10R models.

ΔΣ-Drive Technology - Delta Sigma Drive

The ΔΣ-Drive system represents the pinnacle of Technics' expertise in PWM signal processing. This cutting-edge technology reduces harmonic distortions and suppresses motor vibrations, allowing for smoother and more accurate rotation. This results in more faithful reproduction of audio.

Platter and Vibration Control

The turntable features a three-layered platter made from a combination of brass and aluminium die-cast. It includes a rubber covering on the rear surface to absorb unnecessary resonance. This design not only provides exceptional rigidity and vibration damping but also surpasses the SP-10MK2 in rotational stability and has more than twice the inertial mass of the SL-1200MK5.

Rigidity and Balance

To ensure high rigidity, the SL-1300G employs a body with a two-layered construction uniting BMC and aluminium die-cast chassis. Additional reinforcing ribs are placed between the motor and tone arm to enhance rigidity and vibration damping. The factory adjusts the balance of each turntable using high-precision equipment, with each unit marked with a “BALANCED” sticker to signify proper adjustment.

Power Supply and Noise Reduction

The turntable is equipped with a high-speed switching power supply, which ensures stable power delivery with minimal ripple and humming. This technology eliminates the need for large transformers and reduces mechanical vibrations. The switching frequency of over 100 kHz limits noise interference, enhancing playback clarity. Additionally, the low-noise switching circuit includes a noise detection device and error amplifier to further remove residual noise.

Tonearm and Insulators

The tonearm is crafted from lightweight, rigid aluminium and follows the traditional static-balance universal S-shape. It features a gimbal suspension and high-precision bearing for accurate record tracking. Skilled Japanese artisans manually assemble the tonearm, which includes an auxiliary weight to accommodate various pickup cartridges. For vibration control, the SL-1300G uses special silicon rubber insulators, providing both high damping characteristics and long-term reliability. Additionally, the turntable includes gold-plated phono terminals for detachable cables and a metal shielding construction inside the case to minimise external noise interference.

Part Exchange Available

As you would expect from Fanthorpes hifi, we offer a generous part exchange against the Technics SL1300G Turntable. If you have any hifi that you wish to use as part payment against the Technics SL1300G Turntable then either call us on 01482 223096 or email us at shop@fanthorpes.co.uk  and we will give you a price to change. This is a fantastic and hassle free way of making the Technics SL1300G Turntable more affordable.

Finance Available - No Deposit Required

Fanthorpes hifi can also offer buy now pay later on the Technics SL1300G Turntable, allowing you to spread or defer your payments over a year. If you are interested in taking advantage of our payment terms on the Technics SL1300G Turntable email shop@fanthorpes.co.uk or call us on 01482 223096 and we will email an application form to you

Technics SL1300G Turntable Specification:

• Turntable Section

  • Drive Method: Direct Drive
  • Motor: Brushless DC motor
  • Turntable Speeds: 33-1/3, 45, and 78* rpm
  • Pitch Adjustment Range: ±8% and ±16%
  • Starting Torque: 0.32 N・m (3.3 kgf・cm) (2.86 lbf-in)
  • Build-up Characteristics: 0.7 s from standstill to 33-1/3 rpm
  • Braking System: Electronic brake
  • Wow and Flutter: 0.025% W.R.M.S.
  • Turntable Platter: Aluminium diecast, Brass, and Rubber
  • Diameter: 332 mm (13-5/64")
  • Weight: Approx. 3.6 kg (7-15/16 lbs) (Including a rubber sheet)

  Tonearm Section

  • Type: Static Balance
  • Effective Length: 230mm
  • Overhang: 15mm
  • Tracking Error Angle:
    • Within 2° 32' (outer groove of 30cm/12" record)
    • Within 0° 32' (inner groove of 30cm/12" record)
  • Offset Angle: 22°
  • Arm Height Adjustment Range: 0 - 6mm
  • Stylus Pressure Adjustment Range: 0 - 4g (Direct Reading)
  • Headshell Weight: Approx. 7.6g
  • Applicable Cartridge Weight Range:
    • Without auxiliary weight: 5.6 - 12.0g
    • With head shell: 14.3 - 20.7g
    • With small auxiliary weight: 10.0 - 16.4g
    • With head shell: 18.7 - 25.1g
    • With big auxiliary weight: 14.3 - 19.8g
    • With head shell: 23.0 - 28.5g
  • Cartridge Mounting Dimension: 12.7 mm (1/2") interval
  • Head Shell Terminal Lug: 1.2mmφ 4-pin terminal lug

  Terminals

  • PHONO (Pin Jack): x1
  • EARTH TERMINAL: x1

  General

  • Power Supply: AC220-240 V, 50/60 Hz
  • Power Consumption:
    • 10 W (ON)
    • 0.3 W (OFF)
  • Dimensions (W x H x D): 453 x 173 x 372 mm
  • Operating Temperature Range: 0°C to +40°C
  • Operating Humidity Range: 35% to 80% RH (no condensation)

  Accessories

  • Turntable
  • Turntable sheet
  • Dust cover
  • EP record adaptor
  • Balance weight
  • Auxiliary weight
  • Head shell
  • Overhang gauge
  • Screw set for cartridge
  • PHONO cable
  • PHONO earth lead
  • AC mains lead
  • Screw set for turntable
  • Owner's Manual
