Project Pick It Pro Balanced Cartridge

Project Pick It Pro Balanced Cartridge

The Project Pick It Pro Balanced Cartridge is a technical marvel designed to deliver high-quality audio playback with a focus on precision and performance. Featuring an output voltage of 4 mV, this cartridge ensures a robust signal output, offering a clear and accurate reproduction of your vinyl records. With a channel separation of 22 dB at 1000Hz, it maintains distinct audio channels, contributing to a balanced stereo listening experience.

The cartridge's frequency response spans from 20Hz to 20,000Hz, with a minimal deviation of ± 2 dB, guaranteeing faithful audio reproduction across the audible spectrum. Its impressive tracking ability, measured at 315Hz with the recommended tracking force of 2.0 grams, allows it to navigate the grooves with precision, capturing all the nuances in the record. The compliance, both dynamic and lateral, is measured at 12 μm, providing flexibility for tracking while maintaining audio accuracy.

The Pick It Pro Balanced Cartridge features a tipped elliptical stylus type with a stylus tip radius of 8 / 18 μm. It offers a tracking force range of 1.8 - 2.2 grams, allowing for fine-tuning according to personal preferences. With an internal impedance of 750 Ω and an internal inductance of 450 mH, this cartridge is designed to work seamlessly with a recommended load impedance of 47,000 Ω and a recommended load capacitance ranging from 150 to 300 pF. The cartridge's manageable weight of 7.2 grams ensures compatibility with a wide range of turntables, making it a reliable choice for audiophiles seeking accurate and consistent audio playback.

Part Exchange Available

As you would expect from Fanthorpes hifi, we offer a generous part exchange against the Project Pick It Pro Balanced Cartridge. If you have any hifi that you wish to use as part payment then either call us on 01482 223096 or email us at shop@fanthorpes.co.uk and we will give you a price to change. This is a fantastic and hassle-free way of making the Project Pick It Pro Balanced Cartridge more affordable.

Project Pick It Pro Balanced Cartridge Specifications:

• Output Voltage: 4 mV
• Channel Separation (@ 1000Hz): 22 dB
• Frequency Response (20 - 20,000Hz): ± 2 dB
• Tracking Ability (@ 315Hz at Recommended Tracking Force): 70 μm
• Compliance, Dynamic, Lateral: 12 μm
• Stylus Type: Tipped Elliptical
• Stylus Tip Radius (R/R): 8 / 18 μm
• Tracking Force Range: 1.8 - 2.2 g
• Recommended Tracking Force: 2.0 g
• Tracking Angle: 20°
• Internal Impedance: 750 Ω
• Internal Inductance: 450 mH
• Recommended Load Impedance: 47000 Ω
• Recommended Load Capacitance: 150 - 300 pF
• Cartridge Weight: 7.2 g
